Reference Standards

　　The product is manufactured according to the standards of GB5023-1997 and JB8734-1998 or IEC,BS,DIN and ICEA upon request.

　　Application

　　The products is suitable for power installation fixed wiring or flexible connection for electrical appliances with rated voltage up to and including 450/750V respectively.

　　Operating characteristics

　　Rated voltage Uo/U：450/750V、300/500V、300/300V。

　　Max.permissible continuous operating temperature of the conductor:

　　227 IEC 07(BV-90)…………………………90℃

　　227 IEC 08(RV-90)………………………90℃

　　For other types …………………70℃

　　The ambient temperature under installation shall not below 0℃

　　The bending radius of cable：

　　D≤25mm …………………………………≥4D

　　D>25mm …………………………………≥6D

　　( Diameter of the cable )
